HP-1200T Hermetic Press Machine

You can rest assured to buy HP-1200T Hermetic Press Machine from our factory.Block making machines are mechanical equipment that use fly ash, crushed construction waste, crushed stone, stone powder, etc. as raw materials to produce environmentally friendly new materials such as blocks and cement bricks. New wall materials are mainly blocks and cement bricks. Block making machines are available in different sizes and models, and are able to produce bricks of different shapes and sizes according to their specifications. The main components of a block making machine include a hopper, a mixing drum or pan, a mold, and a conveyor belt or stacking system. Raw materials such as cement, sand and water are mixed in the hopper and poured into the mixing drum. The mixed material is then fed into a mold and compressed under high pressure and vibration to form a shape.

Seven-station cycle brick making

1. Fabric unloading station

2. Fabric dispersing station

3. Maintenance station (mold changing station)

4. Bottom material unloading station

5. Pre-pressing station

6. Main pressing station

7. Demolding station

Technical description

1. The main pressure of the HP-1200T Hermetic Press Machine adopts a large-diameter transition oil tank filling device, which can respond quickly, move sensitively, and can output tons of pressure.

2. The hydraulic station adopts a variable pump, which adjusts the speed and pressure through a proportional valve, which is energy-saving and easy to operate.

3. The turntable adopts an ultra-large slewing bearing, which is controlled by a servo motor with an encoder, with stable operation and precise control.

4. The HP-1200T Hermetic Press Machine adopts an advanced visual control system, and the PLC adopts the Siemens S7-1500 series.

5. The fabric unloading device has a built-in planetary mixer and uses a quantitative turntable for unloading. The unloading amount is accurate and stable each time.

6. The bottom material unloading device of the HP-1200T Hermetic Press Machine can quantitatively unload the bottom material through a variety of transition devices, thereby controlling the height of the finished bricks, greatly saving the number of molds.

Equipment parameters
